Flexible Tube Connectors
Connection Principle 1+
1+100T
Illustration exemplary
Technical information
All data in mm; Illustration exemplary
Technical data
| Connection A | DN08/10 |
| Connection B | DN08/10 |
| Material Body | PVDF |
| Material Pressure Screw | PVDF |
| Pressure Stage | PN16 |
| Max. Media Temperature | 140°C |
Starting from the nominal pressure rating (at 20°C), the permissible pressure reduces with increasing media temperature.
