Straight union with series 1+ flexible tube connections
Illustration exemplary
1+100T43PN

Straight union with series 1+ flexible tube connections

Technical information
All data in mm
All data in mm; Illustration exemplary
Technical data
Connection A DN06/08
Connection B DN06/08
Material Body natural PP
Material Pressure Screw PVDF
Pressure Stage PN16
Max. Media Temperature 90°C
Starting from the nominal pressure rating (at 20°C), the permissible pressure reduces with increasing media temperature.
