Connecting
Flexible Tube Connectors
Connection Principle 1+
1+200MG
Illustration exemplary
1+200MG0518PV
Elbow connector with series 1+ flexible tube connection and male G-thread
Technical information
All data in mm; Illustration exemplary
Technical data
| Connection A | DN1/6"/1/4" |
| Connection B | G1/8" |
| Material Body | PVDF |
| Material O-ring | - |
| Material Pressure Screw | PVDF |
| Pressure Stage | PN16 |
| Max. Media Temperature | 140°C |
Starting from the nominal pressure rating (at 20°C), the permissible pressure reduces with increasing media temperature.
