Connecting
Flexible Tube Connectors
Connection Principle 1+
1+300MG
Illustration exemplary
1+300MG4812PP
T-connector with series 1+ flexible tube connection and male G-thread
Technical information
All data in mm; Illustration exemplary
Technical data
| Connection A | DN10/12 |
| Connection B | DN10/12 |
| Connection C | G1/2" |
| Material Body | PP |
| Material O-ring | - |
| Material Pressure Screw | PP |
| Pressure Stage | PN16 |
| Max. Media Temperature | 90°C |
Starting from the nominal pressure rating (at 20°C), the permissible pressure reduces with increasing media temperature.
