Connecting
Flexible Tube Connectors
Connection Principle 1A
1A100MG
Illustration exemplary
1A100MG4518PN
Straight connector with connection for flexible tube (Series 1A) and male G-thread
Technical information
All data in mm; Illustration exemplary
Technical data
| Connection A | DN08/10 |
| Connection B | G1/8" |
| Material Body | natural PP |
| Material O-ring | - |
| Pressure Stage | PN10 |
| Max. Media Temperature | 90°C |
Starting from the nominal pressure rating (at 20°C), the permissible pressure reduces with increasing media temperature.
