Flexible Tube Connectors
Connection Principle 1C
1C300FG
Illustration exemplary
1C300FG4014PP
T-connector with connections for flexible tube (Series 1C) and female G-thread
Technical information
All data in mm; Illustration exemplary
Technical data
| Connection A | DN04/06 |
| Connection B | DN04/06 |
| Connection C | G1/4" |
| Material Body | PP |
| Pressure Stage | PN10 |
| Max. Media Temperature | 90°C |
Starting from the nominal pressure rating (at 20°C), the permissible pressure reduces with increasing media temperature.
