Connecting
Pipe Connectors
Connection Principle 2M
2M100P
Illustration exemplary
Technical information
All data in mm; Illustration exemplary
Technical data
| Connection A | D4.0 |
| Connection B | D3.0 |
| Material Body | PFA |
| Pressure Stage | PN1 |
| Max. Media Temperature | 180°C |
Starting from the nominal pressure rating (at 20°C), the permissible pressure reduces with increasing media temperature.
