Connection Principle 2N
2N101MG
Illustration exemplary
2N101MG3814PP
Straight bulkhead connector with connection for pipe (Series 2N) and male G-thread
Technical information
All data in mm; Illustration exemplary
Technical data
| Connection A | D04 |
| Connection B | G1/4" |
| Material Body | PP |
| Material O-ring | - |
| Pressure Stage | PN10 |
| Max. Media Temperature | 90°C |
Starting from the nominal pressure rating (at 20°C), the permissible pressure reduces with increasing media temperature.
