Connection Principle 2N
2N101P
Illustration exemplary
2N101P05PF
Straight bulkhead union with connections for pipe (Series 2N)
Technical information
All data in mm; Illustration exemplary
Technical data
| Connection A | D1/4" |
| Connection B | D1/4" |
| Material Body | PFA |
| Pressure Stage | PN10 |
| Max. Media Temperature | 180°C |
Starting from the nominal pressure rating (at 20°C), the permissible pressure reduces with increasing media temperature.
