Regulating Valves Compact 5C
5C101G
Illustration exemplary
5C101G0318PVFP
Compact Valve Series 5C, for panel mounting, straight, with female G- or NPT-thread
Technical information
All data in mm; Illustration exemplary
Technical data
| Nominal Diameter | DN03 |
| Connection A | G1/8" |
| Connection B | G1/8" |
| Material Body | PVDF |
| Material O-ring | FKM |
| Material Spindle | PCTFE |
| Kvs Value | 0.1m³/h |
| Max. Media Temperature | 140°C |
| Pressure Stage | PN10 |
Starting from the nominal pressure rating (at 20°C), the permissible pressure reduces with increasing media temperature.
