Manual Ball Valve 6L
6L702F / 6L802F
Illustration exemplary
6L702F0614PPEP
Ball valve (Series 6L) with female G- or NPT-thread, 3-way, vertical, with L-bore
Technical information
All data in mm; Illustration exemplary
Technical data
| Nominal Diameter | DN06 |
| Connection | G1/4" |
| Material Body | PP |
| Material O-ring | EPDM |
| Material Ball | PP |
| Material Sealing Sleeve | PTFE |
| Material Pressure Screw | - |
| Kvs Value | 0.85 m³/h |
| Max. Media Temperature | 90°C |
| Pressure Stage | PN10 |
Starting from the nominal pressure rating (at 20°C), the permissible pressure reduces with increasing media temperature.
