Shutting Off
Ball Valves
Ball Valve with Pneumatic Actuator 6D
6D702F
Illustration exemplary
6D802F0414PVFP
Ball valve (Series 6D) with pneumatic part-turn actuator (STANDARD), spring return, with female G- or NPT-thread, 3-way, vertical, with L-bore
Technical information
All data in mm; Illustration exemplary
Technical data
| Connection | NPT1/4" |
| Nominal Diameter | DN04 |
| Material Body | PVDF |
| Material O-ring | FKM |
| Material Ball | PVDF |
| Material Sealing Sleeve | PTFE |
| Material Pressure Screw | PVDF |
| Kvs Value | 0.58 m³/h |
| Max. Media Temperature | 140°C |
| Pressure Stage | PN10 |
| Control Pressure | 6 bar |
| Torque | 2.5 Nm |
Starting from the nominal pressure rating (at 20°C), the permissible pressure reduces with increasing media temperature.
