Check valve (Series 5R,) with female G-thread male G-thread, without spring
Illustration exemplary
5R100MF0318PPFK

Check valve (Series 5R,) with female G-thread male G-thread, without spring

Technical information
All data in mm
All data in mm; Illustration exemplary
Technical data
Nominal Diameter DN03
Inlet A G1/8"
Outlet B G1/8"
Material Body PP
Material O-ring FFKM
Material Sealing Cone PTFE
Opening Pressure 0.1 - 0.2 bar
Kvs Value 0.2 m³/h
Max. Media Temperature 90°C
Pressure Stage PN6
Starting from the nominal pressure rating (at 20°C), the permissible pressure reduces with increasing media temperature.
